CHASSIS
- 257-
Rear Bridge
No. Part Name Qty Remarks
Removing the rear bridge
1 Rear reducer assy 1
2
Rear reducer caseⅠ
1
3 Bearing Φ22ΧΦ30Χ13 1
4 Bearing 55Bm6720 Φ55ΧΦ67Χ20 1
5 Drive & driven gears 1
6 Bearing Φ25ΧΦ62Χ17 1
7 Mount bracket, rear disk brake plate 1
8 Oil seal Φ61ΧΦ35Χ9 1
9 Fuel drain O-seal Φ13ΧΦ1.5 1
10 O-ring gasket Φ3ΧΦ71 1
12 Washer Φ12ΧΦ30Χ4 1
13 Hexagon flange nut M12×1.25 1
To Next Page
