CHASSIS
- 283-
COOLING SYSTEM
RADIATOR 1
No. Part Name Qty Remarks
Removing the radiator 1
1 Rear right water pipe 1
2
Clamp
Φ20-32
8
3 Clip , metal water pipe 6
4 Hexagon flange bolt M6×16 8
5 Metal water pipe 2
6 Front water pipe 2
7 Rear left water pipe 1
8 Radiator fan assy 1
9 Installation bracket I, oil cooler 1
10 Installation bracket II, oil cooler 1
11 Radiator assy 1
To Next Page
