CHASSIS

- 296-

OIL SYSTEM

FUEL TANK

No. Part Name Qty Remarks

Removing the fuel tank

1 Fuel tank 1

Insulation paper Ⅸ

3 Shock absorption rubber Φ15-6

4 Fuel pump connection wire assy 1

5 Cover, fuel pump 1

Rubber tube Ⅵ

7 Plug for fuel outlet 1

8 Clip Φ11 1

9 Clamp 8
