ENGINE

- 186 -

DRIVE AXLE ASSEMBLY

No. Part Name Qty Remarks

Disassembling the drive axle Remove the parts in the order listed.

1 Clutch dog 1

2 High wheel gear 1

3 Middle drive gear 1

4 Driven sprocket 1

5 Drive axle 1

For assembly, reverse the disassembly

procedure.
