ENGINE
- 170 -
CLUTCH
No. Part Name Qty Remarks
Removing the clutch Remove the parts in the order listed.
Primary and secondary sheaves
1 Clutch housing assembly 1
2 Gasket/dowel pin 1/2
3 One-way clutch bearing 1
4 Nut 1
5 Clutch carrier assembly 1
For installation, reverse the removal
procedure.
To Next Page
