Hisun HS700UTV-4 - Valves and Valve Springs

ENGINE
- 146 -
VALVES AND VALVE SPRINGS
No. Part Name Qty Remarks
moving the valves and valve springs Remove the parts in the order listed.
Cylinder head cover
1 Valve cotter 10
2 Valve spring retainer 5
3 Intake valve spring 3
4 Exhaust valve spring 2
5 Intake valve 3
6 Exhaust valve 2
7 Valve stem seal 5
8 Valve spring seat 5
For installation, reverse the removal
procedure.
