CHASSIS

- 261-

Speed Reducer Component With Differential

No. Part Name Qty Remarks

Removing the speed reducer

Rear differential case Ⅰ

Rear differential case Ⅱ

3 Oil seal Φ52×Φ35×7 2

4 Bearing 32008E 1

5 C.V Axle, rear right axle 1

6 Rear axle transmission shaft 1

7 Circlip D0=19 1

8 Rear differential comp. 1

9 Circlip Φ20×Φ26×1 1
