CHASSIS
- 285-
RADIATOR 2
No. Part Name Qty Remarks
Removing the radiator 2
1 Oil cooler cover 1
2 Oil cooler 1
3 Oil cooler assy 1
4 Screw hoop Φ12-20 12
5
Pressure-proof rubber oil pipe
Φ
10×
Φ
17×260
2
6 Hexagon flange bolt M6×12 5
7 M-shaped fixed pipe clamps 4
8 M-shaped fixed pipe clamps 4
9 Hexagon flange nut M6 1
10 Hexagon bolt M6 1
11 Pressure-proof rubber oil pipe C 2
