ELECTRICAL COMPONENTS

- 302 -

ELECTRICAL

ELECTRICALCOMPONENTS

1. Thermo switch 2

2. Radiator fan

3.Gear motor

4.Brake light switch

5.Parking brake switch

6.Pickup coil/stator assembly

7.Speed sensor

8. Diode 1

9. Circuit breaker(radiator fan motor)

10.Thermo switch 1

11. Ignition coil

12. Gear position switch

13.Reverse switch

14.ECU unit

15. Windlass controller

16. Windlass
