Hisun HS700UTV-4 - Primary Sheave

ENGINE
- 164 -
PRIMARY SHEAVE
No. Part Name Qty Remarks
Disassembling the primary sheave Remove the parts in the order listed.
1 Primary pulley sheave cap 1
2 Primary pulley slider 4
3 Spacer 4
4 Primary pulley cam 1
5 Primary pulley weight 8
6 Collar 1
7 Oil seal 2
8 Primary sliding sheave 1
9 O-ring 1
For assembly, reverse the disassembly
procedure.
