CHASSIS

- 218-

FRONT AND REAR BRAKE PADS

No. Part Name Qty Remarks

Removing the brake pads Remove the parts in the order listed.

1 Brake caliper mounting bolt 2

2 Brake pad holding bolt 2

3 Brake pad 2 For installation, reverse the removal

4 Pad spring 1 procedure.
