Hisun HS700UTV-4 - Parking Brake Disc

To Next Page

To Previous Page

CHASSIS

- 225-

PARKING BRAKE DISC

No. Part Name Qty Remarks

Removing the parking brake disc

Remove the parts in the order listed.

Brake caliper assembly

Final drive gear

1 Parking brake disc 1

For installation, reverse the removal

procedure.
