Hisun HS700UTV-4 - Transmission

ENGINE
- 185 -
TRANSMISSION
No. Part Name Qty Remarks
Removing the transmission Remove the parts in the order listed.
Crankcase separation
Middle driven gear
1 Low wheel gear 1
2 Shift drum 1
3 Shift fork assembly 1
4 Short spring 1
5 Shift fork 1 1
6 Long spring 1
7 Shift fork 2 1
8 Guide bar 1
9 Secondary shaft 1
10 Drive axle assembly 1
11 Chain 1
For installation, reverse the removal
procedure.
