CHASSIS
- 214-
DISK BRAKE COMPONENTS
No. Part Name Qty Remarks
Removing disk brake components
1 Front brake hose 1
2 Rear brake hose 1
3 Hexagon flange bolt M6×25 1
4 Hexagon flange bolt M6×12 5
5 Oil pipe clip, front disc brake 2
6 Clip, oil pipe 3
7 Rear right brake caliper 1
8 Rear left brake caliper 1
9 Rear right brake plate 1
10 Rear left brake plate 1
11 Hexagon step bolt M8×20 16
12 Bolt M10×1.25×22 8
13 Hexagon flange bolt M6×30 1
To Next Page
