Hisun HS700UTV-4 - Engine Cooling Fan and A.C. Magneto

ENGINE
- 155 -
ENGINE COOLING FAN AND A.C. MAGNETO
No. Part Name Qty Remarks
Removing the engine cooling fan and
A.C. magneto
Remove the parts in the order listed.
Drive belt cover
Engine oil
Coolant
Water pump assembly
1 Engine cooling fan air duct assembly 1
2 Air shroud 1 1
3 Engine cooling fan 1
4 Air shroud 2 1
5 A.C. magneto coupler 2
6 Engine cooling fan pulley base 1
7 A.C. magneto cover/gasket 1/1
8
Dowel pin
2
9 Stator lead holder 1
