CHASSIS
- 246-
Front Bridge
No. Part Name Qty Remarks
Removing the front bridge
1 Front differential assy 1
2
Front differential case Ⅱ
1
3
Front differential caseⅠ
1
4 Drive & driven gears assy 1
5
Connection fork Ⅰ
1
6 Hexagon flange nut M14×1.5 1
7 O-type ring Φ6.8×Φ14 1
8 Oil seal Φ48ΧΦ65Χ9 1
9 Oil seal Φ24ΧΦ38Χ8 2
10
Washer ⅠΦ50ΧΦ61.5
1
11 Socket hexagon screw M8×25 2
