ENGINE

- 171 -

CLUTCH HOUSING

No. Part Name Qty Remarks

Disassembling the clutch housing

Remove the parts in the order listed.

Oil seal

Circlip

Bearing housing

Circlip

Bearing

Circlip

Bearing

Clutch housing

For assembly, reverse the disassembly

procedure.
