MAINTENANCE AND ADJUSTMENT OF THE UTV
- 93-
NOTE:
Recommended oil classification:
API Service “SE”, “SF”, “SG” type or
equivalent (e.g. “SF—SE—CC”,
“SF—SE—SD” etc.)
NOTE:
Do not allow foreign material to enter the
crankcase.
4. Stop the engine and check the oil level
again.
NOTE:
Wait a few minutes until the oil settles
before checking the oil level.
NOTE:
Never remove the dipstick just after high
speed operation because the heated oil
could spurt out. Wait until the oil cools
down before removing the dipstick.
5. Install:
·console
·passenger seat
·driver seat
Refer to “SEATS” in chapter 5.
CHANGING THE ENGINE OIL
Place the vehicle on a level surface.
1. Start the engine and let it warm up for
several minutes.
2. Stop the engine and place an oil pan
under the engine.
3. Remove:
·driver seat
·passenger seat
·console
4. Remove:
·engine oil filler plug (dipstick) ①
·engine oil drain bolt ② Drain the engine oil
from the crankcase.
To Next Page
