Hisun HS700UTV-4 - Suspension; Front Suspension and Arm

CHASSIS
- 271-
SUSPENSION
Front Suspension and arm
No. Part Name Qty Remarks
Removing front suspension and arm
1 Left front upper swing arm 1
2
Joint A，suspension
4
3 Circlip D0=30 4
4 Right front upper swing arm 1
5 Left front lower swing arm 1
6 Right front lower swing arm 1
7 Middle rubber tube, swing arm 8
8 Hexagon flange bolt M10×1.25×70 8
