CHASSIS
- 272-
No. Part Name Qty Remarks
9 Hexagon flange nut M10×1.25 12
10 Dust cover B 16
11 Hexagon nut M12×1.25 4
12 Cotter Pin 2.5×30 4
13 Front shock absorber 2
14 Hexagon flange bolt M10×1.25×50 2
15 Protective board, swing arm 2
16 Screw thread clip M6×5 4
17 Cross big plate head screw M6×12 4
18 Tie-rod, front anti-roll bar 2
19 Hexagon flange bolt M10×1.25×45 2
To Next Page
