CHASSIS
- 273-
No. Part Name Qty Remarks
20
"U" type rubber bush Φ21-40 2
21 Press block, rear anti-roll bar 2
22 Hexagon flange bolt M8×22 4
23 Front anti-roll bar 1
24 Spring washer -8 4
25 Hexagon flange bolt M10×1.25×75 2
26 Dust proof rubber boot 4
27 Washer Φ13×Φ24×2 2
28 Spring washer -12 4
29 Washer Φ8×Φ16×1.6 4
30 Hexagon flange lock nut M8 4
