CHASSIS
- 274-
DISASSEMBLING, SERVICE AND ASSEMBL
THE SUPPORTING ROCKER PARTS
1. Disassembling and Service
In the suspension, there is easy to appear the
problem with bushing, cotter pin and shock
absorber.
• If the left and right rocker rocks fiercely, check
the few aspect, whether the bushing of the
rocker is crushed, the middle rubber separate
is aging and chapped.
• check whether the cotter pin is credible, if it is
not instead the same spec cotter pin.
• The problem with the shock absorber and
maintain method, whether it can returns to the
position under the pressure and the torsional
spring is rupture. If it is rupture or nearly to
rupture, instead the shock absorber. whether it
leak oil, if so instead the same spec shock
absorber. According to the different request, i
there is a oil cup on the rocker, must check it
whether complete and refuels.
2. Installing
• Use 16 pieces of Hexagon Flange Bolt
M10×70 and 16 pieces of bolt to connect the
front upper left and right rocker, front lower L/R
rocker, rear upper L/R rocker and rear lowe
L/R rocker with the frame. To ensure the
fastening torque is 40-45Nm.
• Connect the front shock absorber, frame and
rocker with 4 pieces of Hexagon Flange Bolts
M10×52 and 4 pieces of self-lock nuts M10.
• Connect the rear shock absorber and rea
lower rocker combination with 2 pieces o
Hexagon Flange Bolts M10×65 and 2 pieces
of self-lock nuts M10.
• Connect the rear shock absorber and frame
with 2 pieces of Hexagon Flange Bolts
M10×70 and 2 pieces of self-lock nuts M10.
1NOTE:
1. Put on the butter to each part when it is
assemble.
2. Do not scratches the surface of the spare
part surface.
