Hisun HS700UTV-4 - Rear Suspension

CHASSIS
- 277-
Rear Suspension
No. Part Name Qty Remarks
Removing the rear suspension
1 Rear shock absorber 2
2 Hexagon flange bolt M12×1.25×70 2
3 Hexagon flange bolt M12×1.25×65 2
4 Hexagon flange nut M12×1.25 4
5 Rear anti-roll bar 1
6 Left tie-rod, anti-roll bar 1
7 Right tie-rod, anti-roll bar 1
8 Hexagon flange nut M10×1.25 2
9
"U" type rubber bush Φ21-40
2
10 Press block, rear anti-roll bar 2
11 Hexagon flange bolt M8×22 4
