Hisun HS700UTV-4 - Electric Starting System; Circuit Diagram

ELECTRICAL COMPONENTS
- 310 -
resistance
0.063 ~ 0.077 Ω at 20 °C (68 °F)
(Red – White/Blue)
MEETS SPECIFICATION
10.Wiring connection
• Check the connections of the entire ignition
system. Refer to “CIRCUIT DIAGRAM”.
CORRECT
Replace the ECU. unit
ELECTRIC STARTING SYSTEM
Circuit diagram
（See 370 page）
OUT OF SPECIFICATION
Replace the pickup coil/stator assembly.
POOR CONNECTION
Properly connect the ignition system.
