ENGINE

- 177 -

CRANKCASE BEARINGS

No. Part Name Qty Remarks

Removing the crankcase bearings Remove the parts in the order listed.

Crankshaft and oil pump

Transmission

Middle drive/driven shaft

1 O-ring/collar 1/1

2 Oil seal 1

3 Bearing retainer 1

4 Bearing 9

For installation, reverse the removal

procedure.
