CHASSIS

- 286-

No. Part Name Qty Remarks

Pressure-proof rubber oil pipe Φ10×Φ17×150

工-shaped rubber washer

14 Front right metal oil pipe 1

15 Front left metal oil pipe 1

16 Rear right metal oil pipe 1

17 Rear left metal oil pipe 1
