CHASSIS
- 258-
No. Part Name Qty Remarks
14
Rear adjustment gasketⅠ
1
15 Hexagon bolt with washer 4
16 Socket hexagon screw M8×25 1
17
Rear adjustment gasket Ⅱ
1
18 Speed sensor comp. 1
19 O-ring gasket, fuel injection Φ2.3ΧΦ19.4 1
20 Vent pipe, rear reducer 1
21
Rear reducer case Ⅱ
1
22 Socket hexagon screw M8×45 1
23 Washer Φ8.2Χ1 4
24 Hexagon flange nut M8 2
25 Oil seal Φ65×Φ90×9 1
26 Bearing 16017C2 Φ85ΧΦ130Χ14 1
To Next Page
