CHASSIS
- 259-
No. Part Name Qty Remarks
27 O-ring Φ3ΧΦ150 2
28
Adjustment gasket Ⅲ
1
29 Oil seal Φ65×Φ90×9 1
30 Fuel drain screw plug 1
31 Hexagon flange nut M10×1.25×25 1
32 Hexagon flange bolt M8×12 4
33 Rear transmission shaft comp 1
34 Spring Φ18.5×Φ2×30 1
35 Rear transmission shaft 1
36 Circlip D0=19 2
37 Jointsleeve, rear axle transmission shaft 1
38 Elasticity block ring D0=22 1
39 Hexagon flange nut M10×1.25 2
