ENGINE
- 173 -
3、INSTALL
• clutch carrier assembly
• nut (① 160Nm)
1NOTE:
Use a universal clutch holder to hold the②
clutch carrier assembly.
• Lock the threads with a drift punch.
• one-way clutch bearing
1NOTE:
The one-way clutch bearing should be
installed in the clutch carrier assembly with
the arrow mark (a) facing toward the clutch
housing.
• dowel pins
• gasket
• clutch housing assembly
(10 Nm)
1NOTE:
• Tighten the bolts in stages, using a crisscross
pattern.
• After tightening the bolts, check that the clutch
housing assembly to counterclockwise rotates
smoothly.
