ENGINE
- 137 -
1、CHECK
1). Checking the valve clearance
• Valve clearance
Refer to “ADJUSTING THE VALVE
CLEARANCE” in chapter 3.
2). Checking the cylinder head cover
• cylinder head cover
Cracks/damage
Replace the cylinder head
cover and cylinder head as a set.
3). Checking the tappet covers
• tappet cover (exhaust) ①
• tappet cover (intake) ②
Cracks/damage
Replace.
• O-rings ③
NOTE:
When installing, new replacement washer
and apply wheel bearing grease LS.
4). Removing the screwdriver and slowly release
the timing chain tensioner rod.
NOTE:
Make sure that the timing chain tensioner rod
comes out of the timing chain tensioner housing
smoothly. If there is rough movement,
replace the timing chain tensioner.
To Next Page
