ENGINE
- 159 -
• engine cooling fan pulley (55Nm)①
1NOTE:
Before installing the engine cooling fan
pulley, do not forget to install the O-ring.
• engine cooling fan ① (7Nm)
1NOTE:
Install the bolts in the holes in the collar of
the engine cooling fan.
• air shroud ① (10Nm)
• engine cooling fan air duct assembly ①
1NOTE:
Install the engine cooling fan air duct
assembly with the arrow mark (a) towards
the air shroud .①
To Next Page
