ENGINE
- 162 -
• balancer driven gear
1NOTE:
Align the punch mark (a) on the balancer
drive gear with the punch mark (b) on the
balancer driven gear.
• lock washer(new replacement)
• balancer driven gear nut ①(110Nm)
1NOTE:
• Place an aluminum plate ② between the
teeth of the balancer drive gear ③ and
balancer driven gear ④.
• Apply the molybdenum disulfide grease to
the thread of axle and nut.
To Next Page
