ENGINE

- 180 -

2). Installing the shift levers

• shift lever 2 assembly ① (14Nm)

• shift lever 1 ②

1NOTE:

When installing the shift lever 1, align the

punch mark (a) on the shift lever 1 with the

punch marks (b) on the shift lever 2.
