ENGINE
- 189 -
3、INSTALL
1). Assembling the shift fork
• guide bar ①
• shift fork 2 ②
• long spring ③
• shift fork 1 ④
• short spring ⑤
2). Installing the transmission
• chain ①
• drive axle assembly ②
• secondary shaft ③
• shift fork assembly ④
• shift drum ⑤
• low wheel gear
1NOTE:
• Oil each gear and bearing thoroughly.
• Before assembling the crankcase, be sure
hat the transmission is in neutral and that
the gears turn freely.
