ENGINE
- 196 -
• drive shaft coupling
• washer
• nut ①(97Nm)
1NOTE:
Use the coupling gear/middle shaft tool ②
to hold the drive shaft coupling.
2). Installing the middle drive shaft
(1) Tighten:
• middle drive pinion gear nut ① (145Nm)
1NOTE:
Secure the middle drive shaft in the vise with
a clean rag.
(2) Lock the threads with a drift punch.
