CHASSIS

- 202-

No. Part Name Qty Remarks

22 Hexagon flange nut M12×1.25 1

23 Decoration cover for steering column 1

24 Down cover for steering wheel 1

25 Washer Φ10×Φ20×2 4

26 Spring washer -10 4

27 Washer Φ8×Φ16×1.6 4

28 Washer Φ15×Φ28×2 1

Cross small plate head tapping screw

ST3.6×10
