CHASSIS
- 206-
No. Part Name Qty Remarks
33 Lower cover, ignition switch 1
34 Tapping Clamp F4.2 3
35 Washer Φ5×Φ15×1.2 3
36 Decoration cover, steering column 1
37 Rubber cushion, ignition switch cover 1
38 Lower cover, steering wheel 1
39 Washer Φ10×Φ20×2 4
40 Spring washer -10 4
41 Washer Φ8×Φ16×1.6 4
42 Washer Φ15×Φ28×2 1
43
Cross small plate head tapping screw
ST3.6×10
3
To Next Page
