Hisun HS700UTV-4 - Page 303

CHASSIS
- 290-
No. Part Name Qty Remarks
14
Pipe clip Ⅱ
1
15 Save temperature 1
16 Save temperature cover 1
17 Bolt M6×20 2
18 Water pump housing cover 1
19 Gasket 1
20 Circlip 1
21 Impeller assembly 1
22 Water pump seal 1
23 Oil seal 1
24 Bearing 1
25 Water pump housing 1
26 O-ring 1
18
19
20
25
21
22
24
23
26
10Nm (1.0m · kg,7.2 ft · lb)
12Nm (1.2m · kg,8.7 ft · lb)
