CHASSIS

- 293-

3. Install:

• rubber damper ①

• rubber damper holder ②

1NOTE:

• Before installing the rubber damper, apply

tap water or coolant onto its outer surface.

• Make sure that the rubber damper and

rubber damper holder are flush with the

impeller.
