Hisun HS700UTV-4 - Page 79

SPECIFICATIONS
- 66 -
Item Standard Limit
Stem-to-guide clearance IN
EX
Stem runout limit
Valve seat width
IN
EX
0.010 ~ 0.037 mm
(0.0004 ~ 0.0015 in)
0.025 ~ 0.052 mm
(0.0010 ~ 0.0020 in)
----
0.9 ~ 1.1 mm
(0.0354 ~ 0.0433 in)
0.9 ~ 1.1 mm
(0.0354 ~ 0.0433 in)
0.08 mm
(0.0031 in)
0.10 mm
(0.0039 in)
0.01 mm
(0.0004 in)
----
----
Valve spring
Inner spring
Free length IN
EX
Set length (valve closed) IN
EX
Compressed pressure
(installed) IN
EX
Tilt limit
* IN
EX
Direction of winding
(top view)
IN
EX
32.63 mm (1.28 in)
36.46 mm(1.44 in)
27.5 mm (1.08 in)
31.0 mm(1.22 in)
100.0 ~ 115.7 N
(10.20 ~ 11.80 kg, 22.49 ~ 26.01 lb)
120.6 ~ 138.3 N
(12.30 ~ 14.10 kg, 27.12 ~ 31.09 lb)
----
----
Clockwise
Clockwise
31.0 mm
(1.22 in)
34.6 mm
(1.36 in)
----
----
----
2.5°/1.4 mm
(2.5°/0.055 in)
2.5°/1.6 mm
(2.5°/0.063 in)
----
----
