9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
Icon Identication
Icon Identication
MODEL
The model menu contains the model programming for the active model.
ACRO
Menu for xed wing, glow, gas and some electric models.
GLID
Menu for gliders and some electric models.
HELI
Menu for rotary wing aircraft.
EXIT DOOR
Appears in the upper right corner, the “go back” icon.
FOLDER
The custom menu. Often used, or “quick access” feature folder.
WRENCH
The system menu contains model set-up and transmitter feature menus.
ADJUST
The adjustment menu contains the adjustment features for quick access.
AILE
Aileron for xed wing menus and the “roll” swash input for helis.
ELEV
Elevator for xed wing menus and the “pitch” swash input for helis.
RUDD
Rudder for xed wing menus and the “yaw”, or tail rotor input for helis
.
1/2, 1/3, 1/6 FRACTIONS
Indicates the number of pages in the menu. Press to access the next page.
+ RST –
Often used Aurora menu value input icons. Value adjustment icon
+
/
–,
RST : Reset
Arrow
Press to cycle through menu options.
C
Combination icon. Flight mode option, “groups” the ight mode values.
S
Separate icon. Flight mode option, “separates” the ight mode value.
INH
Inhibit is used to “turn o” a function.
SEL
Select is used to “select” a feature of the displayed menu.
ACT
Active, “turns on” a function.
NULL
“No switch” selected, the function or feature will be “on” all the time.
AUX
An “open” channel, without a control assigned to it.
J1
Right gimbal, up and down control.
J2
Right gimbal, side to side control
J3
Left gimbal, up and down control.
J4
Left gimbal side to side control.
T1
J1 control trim.
T2
J2 control trim.
T3
J3 control trim.
T4
J4 control trim.
LT
Left VR switch.
CT
Center VR switch.
RT
Right VR switch.
RS
Right slider control.
LS
Left slider control.
Multi-I/O
File sharing, trainer and PC interface mode.
DataTran
User can up / down load model setup data thru a PC.
T.Pupil
Aurora in pupil, or training mode
.
10
To Next Page
