HITEC Aurora 9X - Ail- Flp; Aileron to Flap MIX

9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
108
AIL- FLP (ACRO and GLID)
d. The Aurora 9X oers a 7 point curve on many of
our adjustable mix menu items. To adjust the
travel values, move the corresponding control
stick or slider to align the moving line with the
point you wish to adjust. press the + or - icon to
adjust to the desired curve points. If you wish to
inhibit any curve points, press the RST icon. It is
necessary to inhibit the #2, 3, 5 and 6 points, and
to just adjust points 1 and 7 equally to achieve a
linear curve.
e. Click the arrow icon to set the values of the
ap 2(If ap 2 is existed)
f. Select the Exit icon to return to the model menu.
a. Select the AIL
-FLP icon in the model menu.
b. Select ACT to activate the feature.
Switch Option and In –Flight Fine Trim Adjustment Switch Function
c. To select a 2 position switch that will turn the mix on and o, select an “in-ight” ADJUSTMENT switch,
and to apply a trim link, press NULL and follow the switch activation process on page 68.
Switch type Function Trim link VR adjustment
2 position On or o Yes, T.APP Fine tuning control choice
Aileron to Flap Mix.
Aileron to ap mix can be set up to allow the full trailing edge of the wing (aps and ailerons) to move together, acting
as one large aileron on each wing panel.
### This function can be inuenced by the ight condition feature ###
