HITEC Aurora 9X - Flap to Elevator MIX.; Flp con

9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
110
FLP CON (ACRO and GLID)
a. Select the FLP CON icon from the model menu.
b. Press ACT to activate the Flap Control menu.
d. The Aurora 9X oers a 7 point curve on many of
our adjustable mix menu items. To adjust the
travel values, move the corresponding control
stick or slider to align the moving line with the
point you wish to adjust. press the + or - icon to
adjust to the desired curve points. If you wish to
inhibit any curve points, Press the RST icon. It is
necessary to inhibit the #2, 3, 5 and 6 points,
and to just adjust points 1 and 7 equally to
achieve a linear curve.
e. Click the arrow icon to set the values of the
ap 2 (If ap 2 exists).
f. Note the addition of the elevator as the ap
control is moved.
g. Select the Exit icon to return to the model menu.
Flap to Elevator Mix.
Flap Control will mix the elevator into any ap movement to avoid pitch changes as aps are deployed.
### This function can be inuenced by the ight condition feature ###
Switch type Function VR adjustment
2 or 3 position On or o Fine tuning control choice
Switch Option and In–Flight Fine Trim Adjustment Switch Function
c. To select a 2 or 3 position switch that will allow multiple mix values, select an “in-ight” ADJUSTMENT switch, press NULL and follow
the switch activation process.
