HITEC Aurora 9X - Switch Option and In-Flight Fine Trim Adjustment Switch Function; Elevator to Camber MIX

9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
105
ELE-CAM (ACRO and GLID)
d. The Aurora 9X oers a 7 point curve on many
of our adjustable mix menu items. To adjust
the travel values, move the corresponding
control stick or slider to align the moving line
with the point you wish to adjust. Press the
+ or - icon to adjust to the desired curve points.
If you wish to inhibit any curve points, press
the RST icon. It is necessary to inhibit the #2, 3,
5 and 6 points, and to just adjust points 1 and 7
equally to achieve a linear curve.
e. Click the arrow icon to set the values of the
ap (If ap exits).
f. Again use the +RST- icon to set the value for
the aps. Note the aps will only appear as an
option if you told the radio your model had
aps when it was set up.
g. Select the Exit icon to return to the model
menu.
Switch type Function Trim link
2 position On or O Yes. T.APP
Switch Option and In–Flight Fine Trim Adjustment Switch Function
c. To select a 2 position switch that will turn the mix on and o, select an “in-ight” ADJUSTMENT switch, and choose to activate the trim
link, press NULL and follow the switch activation process.
Elevator to Camber Mix.
The elevator to camber mix allows the model to drop and raise the entire trailing edge of your models wing control
surfaces as the elevator is used.
As in many of the Aurora 9X’s model menu options, there are several airframe variables that are selected and appear in
the dierent menu screens. In the case of the elevator to camber mix, the number of aps and ailerons will appear as a
variable based on the airframe type you told the radio you had at the time of initial model set-up in the system menu.
### This function can be inuenced by the ight condition feature ###
a. Select ELE-CAM from the model menu.
b. Press ACT to activate the mix.
