Page 116 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Non-Crit Diag
<Return>
Active Diags (R)
# #
Shows the number of Non-Critical
Diagnostics that are currently active
Supply Voltage (R)
OK
LOW
HIGH
LOW: Supply voltage is below the low
specification limit
HIGH: Supply voltage is above the high
specification limit.
Elec Module Temp
(R)
OK
OVERTEMP
OVERTEMP: Electronics temperature is
outside the operating range (-40°C to +85°C).
DAC Temp Comp
(R) (HART only)
OK
NO
COMPENSATION
The DAC has not been compensated for
temperature effects. This is a factory
operation.
Sensor Comm (R)
OK
SUSPECT
SUSPECT: The interface between the
Temperature Sensor Module and the
Electronics Module is experiencing
intermittent communication failures.
Display Setup (R)
(HART only)
OK
NVM Corrupt
NVM Corrupt: The Display memory is
corrupt.
Characterized (R)
Yes
No
Yes: Sensor is Characterized
No: Sensor is not Characterized
Charact. Status(R)
OK
FAULT
OK: Characterization table CRC is OK
FAULT: Sensor Characterization data is
corrupted.
When this fault occurred, Sensor Module
fault of Critical Diagnostic will be set.
PV Range (R)
OK
Out Of Range
Out of Range: PV is not within the range
limits
Sensor Over Temp
(R)
OK
OVER TEMP
OVERTEMP: Sensor temperature is greater
than 125°C.
