Honeywell SmartLine SLG 700 User Manual

Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 117
Non-Crit
(continued)
Surface Sgnl Str (R)
Good
Bad
Bad: Signal Strength is bad
Surfac Sgnl Qlty (R)
Good
Bad
Bad: Signal Quality is bad
Interfc Sgnl Str (R)
Good
Bad
Applicable for Two Liquid Products
Bad: Signal Strength is bad
Interfc Sgnl Qlty (R)
Good
Bad
Applicable for Two Liquid Products
Bad: Signal Quality is bad
Sensing Section (R)
OK
FAULT
This is a roll-up status that is set when any
of the following non-critical status
conditions are present:
 Sensor Over Temperature
 Level is in upper blocking distance zone.
 Level is in lower blocking distance zone.
 Sensor Not Characterized
 Sensor Not Calibrated
Blk Dist Hi Zone (R)
(single liquid only)
Yes
No
These parameters mark regions outside
accurate measurement.
If the level enters either of these regions
then Status = Unknown.
Blk Dist Lo Zone (R)
(single liquid only)
Surface in BDH (R)
(two liquids only)
Yes
No
These parameters mark regions outside
accurate measurement.
If the surface level enters either of these
regions then Status = Unknown.
Surface in BDL (R)
(two liquids only)
Interface in BDH (R)
(two liquids only)
Yes
No
These parameters mark regions outside
accurate measurement.
If the interface level enters either of these
regions then Status = Unknown.
Interface in BDL (R)
(two liquids only)
Snsr Calibrated (R)
Yes
No
Yes: Sensor is calibrated
No: Sensor is not calibrated
Calibration Type (R)
Standard
Custom
Standard: Device is calibrated for
standard points.
Custom: Device is calibrated for user-
defined points.
FldBkgdNotCompat
Yes
No
Yes: The Field Background is not
compatible.
Backgrnd Not Set
Yes
No
Yes: The Background is not set.
FldgBkgdLoadError
Yes
No
Yes: Field Background loading error.
