Page 118 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Non-linearized
product level
HART only.
If linearization is disabled then Product
Level and Measurd Prod Lvl will be same.
Signal strength depends on a function of
distance and the medium. As the level and
interface peaks are negative, a more
negative value indicates a better signal.
Signal strength improves as distance
decreases.
Normal range: (-500) – (-9000)
Interface
Signal Strength
For 2 liquid cases
Quality measurements range:
0 – 1
Less than 0.3 = Bad
0.6 -- 0.8 = Good
1 = Perfect
Interfc Sgnl Qlty
(R)
(two liquids only)
Interface
Signal Quality
For 2 liquid cases
Int Elec Temp (R)
(two liquids only)
Internal
Electronics
Temperature
Internal temperature measurement of the
sensing module.
Firmware version of display module
Firmware version of communications
module
Communications protocol of transmitter
Universal Rev (R)
(HART only)
Applicable only for HART device
Revision of Hart specification
Field Dev Rev (R)
(HART only)
Applicable only for HART device.
HART HCF hardware revision
For DD/DTM compatibility
Software Rev (R)
(HART only)
Applicable only for Hart device
Hart HCF software revision
PV Alarm Type (R)
(HART only)
Applicable only for HART device
Loop current behavior during critical fault.
HIGH : 21.5mA
LOW : 3.5mA
Displays the analog output will be scaled
to 4mA.
Displays the measuring value for which
the analog output will be scaled to 20mA.
Firmware version of sensor module
Type and range of transmitter
Unique for each device considered as
serial number
