state. Programming a specific value for POWer :
AMPLif
ier : STATE sets
POWer:AMPLifier:STATE:AUTOto OFF.
*RSTvalue
is ON.
l POWer:ATTenuation
<num>[DB]
lMAXimumlMINimumlUPlDOWN
l
POWer :
ATTenuat
ion?
[MAXimum
I
MINimum]
Sets and queries the output attenuation level. Note that when
setting the attenuator level to 10 dB the output power is
decreased by 10 dB. Programming a specified attenuation sets
POWer :
ATTenuat
ion : AUTO OFF.
l POWer:ATTenuation:AUTO ONlOFFlllO
a
POWer:ATTenuation:AUTO?
Sets and queries the state of the RF attenuator coupling switch.
Programming a specified attenuation sets
POWer:ATTenuation:AUTO OFF.
ON
-
insures that the amplitude level of the ALC is kept within
optimal limits.
OFF
-
the attenuator setting is set to the value of POW :ATT and left
there. The *RST value is ON.
l POWer:CENTer
Cnum>
[lvl
suffix]
lMAXimumlMINimumlUPlDOWN
l POWer:CENTer?
CMAXimumlMINimuml
Sets and queries the center power for power sweep. Default units
(and units for query response) are determined by the UNIT:POWer
command.
The coupling equations for power sweep are exactly analogous to
those for frequency sweep. Power sweep is allowed to be negative,
unlike frequency sweeps. See
FREQ
: CENT for a description. *RST
value is 0
dBm.
l
POWer[:LEVell
<num>[lvl
suffix]
lMAXimumlMINimumlUPlDOWN
l
POWer
C
:
LEVelI
?
[MAXimum
I
MINimumI
Sets and queries the output level. Default units and units
for the query response are determined by the UNIT:POWer
command. Maximum and minimum levels refer to the
leveling mode at the time the command is sent. For example,
*RST;
POWer :
LEVel
MIN; ALC :
SOURce
MMHead has different effects
from
*RST;POWer:ALC:SOURce
MMHead; POWer:LEVelMIN
After
*RST,
the value is 0
dBm.
l
POWer:MODE
FIXedlSWEep
l
POWer : MODE?
Sets and queries the setting of the power sweep mode switch. If in
the sweep mode then the output level is controlled by the start,
stop, center and span functions. If in the fixed power mode then the
output is controlled by the POW C: LEVEL] command. The *RST value
is FIXed.
Operating and Programming Reference S-37
