SCPI
COMMAND SUMMARY
Sets and queries the instrument, whether it is in master or slave
mode. This applies in a dual source mode. *RST value is MASTer.
l
SWEep:DWELl
Cnum>Ctime
suffixllMAXimumlMINimum
l
SWEep :
DWELl?
[MAXimum
I
MINimumI
Sets and queries the amount of time in seconds that the instrument
stays (dwell) at each step after reporting a
source settled SRQ
and
pulsing the Trigger
Out
line low. This one value is used at each step
when in the SWE:TRIG: SOUR IMM mode of a stepped sweep. Setting
SWEep :DWELL sets SWEep :DWELl
:AUTO
OFF. *RST value is 100
ps.
l
SWEep:DWELl:AUTO
ONlOFFlllO
l
SWEep:DWELl:AUTO?
Sets and queries the state of the automatic dwell calculation switch.
Setting SWEep : DWELL sets SWEep
:DWELl
: AUTO OFF. *RST state is OFF.
Combining the Sweep Mode With the Sweep Generation Command
to Obtain the Desired Sweep Condition
Description of
Sweep Condition
CW Non-swept
Analog
freq
sweep
Manual analog
freq
sweep
Stepped freq sweep
Manual step
freq
sweep
CW with analog power
sweep
ZW
with manual analog
power sweep
ZW
with stepped power
sweep
ZW
with manual stepped
lowe*
sweep
4nalog frequency and
power sweep
Manual analog frequency
and power sweep
Stepped frequency and
power sweep
Manual stepped frequency
and power sweep
List sweep
Manual list sweep
FREQ
:POW
:MODE
:MODE
cw FIX
SWE FIX
SWE FIX
SWE FIX
SWE FIX
cw SWE
CW
SWE
cw
SWE
cw SWE
SWE
SWE
SWE SWE
SWE
SWE
SWE SWE
LIST
ignored
LIST
ignored
SWE
:LIST
:MODE
:MODE
ignored
ignored
AUTO
ignored
MAN
ignored
AUTO
ignored
MAN
ignored
AUTO
ignored
MAN
ignored
AUTO
ignored
MAN
ignored
AUTO
ignored
MAN
ignored
AUTO
ignored
MAN
ignored
ignored
AUTO
ignored
MAN
l
SWEep:GENeration
STEPpedlANALog
l
SWEep :
GENerat
ion?
Sets and queries the type of sweep to be generated: an analog sweep
SWE
:GEN
ignored
ANAL
ANAL
STEP
STEP
ANAL
ANAL
STEP
STEP
ANAL
ANAL
STEP
STEP
ignored
ignored
