HPE OfficeConnect 1920S8G series

MAC Table 199
Interface Index The Interface Index of the MIB interface table entry associated with the source port. This
value helps identify an interface when using SNMP to manage the switch.
Status Provides information about the entry and why it is in the table. Possible values are the
following:
 Learned—The address has been automatically learned by the switch and can age out
when it is not in use. Dynamic addresses are learned by examining information in incom-
ing Ethernet frames.
 Management—The burned-in MAC address of the switch.
 Self—The MAC address belongs to one of the physical interfaces on the switch.
 Other—The address was added dynamically through an unidentified protocol or method.
 Unknown—The switch is unable to determine the status of the entry.
Field Description
